PLC 2 Analog Inputs, 2 Analog Outputs, expansion module

PLC 2 Analog Inputs, 2 Analog Outputs, expansion module

PLC Extension Module - 2 Analog Inputs, 2 Analog Outputs

K533-04IV

810,60 lei

Add to cart

By buying this product you can collect up to 81 loyalty points. Your cart will total 81 points that can be converted into a voucher of 8,10 lei.

6 other products in the same category:

More info

PLC Extension Module - 2 Analog Inputs, 2 Analog Outputs

Input channel    2 (4-20mA, 1-5V, 0-20mA, 0-10V signals are optional)
Measurement accuracy    0.3% F.S
Output channel    2 (4-20Ma, 1-5V, 0-20mA, 0-10V signals are optional)
Output accuracy    0.5% F.S
Parameter configuration    Parameters of each channel can be configured by Kincobuilder software separately
Signal limitation    Input current of each channel shall not exceed 24mA, input voltage shall not exceed 12V. The value of output channel is not allowed to exceed chosen range
Error indication    Red LED of each channel indicates input signal exceeds measurement range
Module width    50mm
