THE 1ST AND UNIQUE IR/IR+EXT. TEMPERATURE DATALOGGING PRINTER INTEGRATED 5 FUNCTIONS IN ONE :PROGRAM/MEASURE/ RECORD/DOWNLOAD/PRINT W/ DOT MATRIX LCM DISPLAY
IR MEASUREMENT FEATURES EMMISSIVITY ADJUSTABLE, HIGH RESOLUTION, LASER BEAM
ABLE TO MANUALLY RECORD UP TO 99 POINTS UNIQUE FUNCTION : USER MAY EDIT LOCATION NAMES FOR EACH MEMORY, MAY FIRST PRESET ON PC
AUTOMATICALLY LOGGING UP TO 12000 POINTS
BUILT-IN TRIPOD RECEPTACLE
9812: FEATURES EXTERNAL EMP.MEASUREMENT
Measuring range:
-40grdC...500grdC - IR(both)
-20grdC...150grdC - Probe (#9812)
Accuracy: IR: ±2% or 2grdC(-20grdC to 399grdC);
±3% or 3grdC in other ranges, whichever is greater. External Temperature (#9812):
-20~0grdC(±1.2grdC); 0~50grdC(±0.8grdC);
Printing modes:
a)To print manually record data in Memory mode , or
b)To print in Automatically record data in Logger mode
where shows the data with Begin/Start/End/Suspend dates and time .total records and sample rate ,or
c)To print Set up data in Setting mode where shows LCM cont. prn cont. unit, date and auto power off time, enable or disable ID..
50~100grdC(±1.6grdC), 100~150grdC(±3.0grdC)
(IR)Emissivity adjustable from 0.3 to 1.0 by 0.1 resolution.
(IR)Resolution : 0.1grdC ( (IR)Distance ratio: 8:1
(IR)Responsetime: 0.2 seconds.
Weight: 370g
Standard packing : Includes meter, batteries, operation manual, CD software and RS232 D-sub connector,printing paper roll. Optional accessory: Ext. Probe(VZ981PAZ).
